1800kg Mini 0.1m3 Small Excavator with Breaker

1800kg Mini 0.1m3 Small Excavator with breaker or clamp (steel track is available)

Overall Dimensions
Overall size: 3800x1050x2280 mm
Ground clearance: 485 mm
Track length: 1630 mm
Track width: 230 mm
Undercarriage width: 1050 mm
Undercarriage ground clearance: 235 mm
Dozer Blade: 1050x240 mm

Engine
Model: LAIDONG KM385B, diesel engine, 18.1kW/2200rpm
Type: Direct injection, water cooled, natural intake
No. of cylinder: 3

Hydraulic System
Hydraulic system working pressure: 16 Mpa
Hydraulic Pump: TJHD
Hydraulic pump flow: 2×22+8.8 L/min
Swing Motor: Eaton
Traveling Motor: Eaton
Fuel Tank Capacity: 26 L
Hydraulic Tank Capacity: 27 L

Main Performance
Swing Speed: 10-12 r/min
Traveling Speed: 2.8 km/H
Grade ability: 70(35°) %
Traveling Tracking Force: 15 kN
Bucket Digging Force: 11.5 kN
Arm Digging Force: 9.3 kN

Operation parameters
Operation Weight: 1800 kg
Bucket Capacity: 0.1 m3
Max. Digging Radius: 3860 mm
Max. Digging Depth: 2050 mm
Max. Digging Height: 3370 mm
Max. Dumping Height: 2390 mm
Max. Dozer Cutting: 270 mm
Max. Dozer Lifting: 235 mm
Boom Deflexion (Left/Right): 75/45 °
Tail Swing Radius: 1125 mm
Front Min. Swing Radius: 1720 mm

Overall Dimensions
Overall size	mm	3800x1050x2280
Ground clearance	mm	485
Track length	mm	1630
Track width	mm	230
Undercarriage width	mm	1050
Undercarriage ground clearance	mm	235
Dozer Blade	mm	1050x240
Engine
Model	LAIDONG KM385B, diesel engine, 18.1kW/2200rpm
Type	Direct injection, water cooled, natural intake
No. of cylinder	3
Hydraulic System
Hydraulic system working pressure	Mpa	16
Hydraulic Pump	Gear Pump	TJHD
Hydraulic pump flow	L/min	2×22+8.8
Swing Motor		Eaton
Traveling Motor		Eaton
Fuel Tank Capacity	L	26
Hydraulic Tank Capacity	L	27
Main Performance
Swing Speed	r/min	10-12
Traveling Speed	km/H	2.8
Grade ability	%	70(35°)
Traveling Tracking Force	kN	15
Bucket Digging Force	kN	11.5
Arm Digging Force	kN	9.3
Operation parameters
Operation Weight	KG	1800
Bucket Capacity	m3	0.1
Max. Digging Radius	mm	3860
Max. Digging Depth	mm	2050
Max. Digging Height	mm	3370
Max. Dumping Height	mm	2390
Max. Dozer Cutting	mm	270
Max. Dozer Lifting	mm	235
Boom Deflexion (Left/Right)	°	75/45
Tail Swing Radius	mm	1125
Front Min. Swing Radius	mm	1720
