HOWO A76X4 375HP Dump Truck (ZZ3257M3847N1)

1. based on hundreds of experiments of discharging rate, charging rate, mix rate, twist spring, running performance and absorbability of the experience of the mechanical design, manufacture, welding, we have produced the CLW concrete mixer which is the ideal transportation equipment for the commercial concrete,

2. There are various choices ranged from 8cbm, 9cbm, 10cbm, 12cbm for the customers. We can choose the well-known chassis from the Europe, Japan, Chinese with powerful drive

3. Moreover, the oil pump, motor, and the condenser is adopted the famous foreign production to ensure the quality

4. The production above are just for reference, please contact the sellers without any hesitation if you need the specific affairs requested.

Model	HOWO A7 6*4 Dump Truck A7/375/K43/6x4WA
Curb weight ( kg)	12410
Loading capacity (kg)	30000
Engine	Make: SINOTRUK Fuel: 4-stroke direct injection diesel engine: WD615.96E, 375HP, electronic controlled common rail engine, , 6-cylinder in-line with water cooling, turbo-charging and intercooling Emission standard: EURO III Maximum output: 276kw Displacement: 9.726L
Cab	A7-W low floor lengthening cabin, with air conditioner, MP5 radio system, with great liquid crystal display VDO instrument and the CAN bus German VDO electronic controlled system, all the instruments are the numerical control synchronous motor controlled, all the road use trucks are four-point support fully floating suspension+shock absorbers with transverse stabilizer, both the drive seat and the co-driver seat have the double locking organization safety belts, exterior sun visor, inner side sun shield, electronic glasses and electronic rear view mirror(with heating system), electronic lifting system of the cab, electronically hand throttle, the volume and the channel can be chosen through the steering wheel, the alarming system of the alternator when there is something wrong.
Transmission	HW19710, SINOTRUK 10forward& 1reverse gearbox
Steering	ZF8098, German hydraulic steering with power assistance
Number of axle	3
Driving axle	AC16, SINOTRUK new model engineering off road 16T axle Standard Ratio: 5.45
Axle-loading(kg)	7000+18000(two axle paralleled),
Front axle	HF9 HOWO off road use 9T front axle with disc brake
Rear axle	HC16
Rear track(mm)
Overhang front/rear(mm)	1540/1970, 1540/2070
Wheel base (mm)	4325+1350
Brake System	metal pipeline, ABS with auto adjusting arm
Tires	12.00R20 radial tire Number: 10+1
Approach/departure angle	20/23, 20/22 (° )
Lift of Carriage	Front/Middle (HYVA NETHERLANDS hydraulic front/Middle lifting cylinder )
Van dimension (mm)	6000(6200, 6300)*2300*1050
Overall sizes (mm)	9185(9285)× 2496× 3490
