Mini Skid Steer Loader, Mini Digger with CE Jc75

Mini Skid Steer Loader , Mi Digger with CEMain features of JC75
Compact structure, maneuverable movement suitable for narrow space operation
Close cabin with joystick control system
Extended wheelbase
High flow double output
Double accelerograph control
Auto-leveling system
Multi-function with a wide range of attachments
Hydraulic brake

Model	JC75
Engine model	498
Bore x stroke(mm)	98×105
Rated power (Kw)	55
Rotating speed(rpm)	2450
Number of cylinders	4
Max. torque (N.m)	245
Displacement (L)	3.168
Max. Speed (km/h)	12(8/16)
Tire(track) modei	12-16.5
Operating load(kg)	1050
Lifting	Arc lifting
Bucket capacity(m3)	0.5
Rated flux(L/min)	75
High Flow Flux(L/min)	115
Fuel tank capacity(L)	90
Self weight bucket(kg)	3500

Model Main technical parameter		JC75
A	Overall operating height(mm)	4070
B	Height to bucket hinge pin(mm)	3150
C	Height to top of cab(mm)	2160
D	Height to bottom of level bucket(mm)	2983
E	Overall length without bucket(mm)	2880
F	Overall length with bucket(mm)	3580
G	Dumping angle at maximum height(°)	40
H	Dumping height(mm)	2450
I	Dumping reach(mm)	710
J	Rollback of bucket on ground(°)	30
K	Rollback of bucket at full height(°)	104
L	Wheelbase(mm)	1115
M	Ground clearance(mm)	205
N	Angle of departure(°)	20
O	Front turning radius without bucket(mm)	1250
P	Front turning radius(mm)	2112
Q	Rear turning radius(mm)	1774
R	Rear axle to bumper(mm)	1082
S	Tread width, centerline to centerline(mm)	1500
T	Width(mm)	1880
U	Bucket width(mm)	1880
