0.5t/26kw/0.25m3 Jc35 with CE Skid Steer Loader

  • 0.5t/26kw/0.25m3 Jc35 with CE Skid Steer Loader
  • USD 10000.00 /Unit
  • 1 Unit
  • 69 Unit
  • 30 days
Product Description
0.5t/26kw/0.25m3 jc35 with CE Skid Steer LoaderMain features of JC35
Compact structure, maneuverable movement suitable for narrow space operation
Open cabin with mechanical control system
Multi-function with a wide range of attachments
Hydraulic brake0.5t/26kw/0.25m3 Jc35 with CE Skid Steer Loader
ModelJC35
Engine model390
Bore x stroke(mm)90×95
Rated power (Kw)26
Rotating speed(rpm)2600
Number of cylinders3
Max. torque (N.m)102.8
Displacement (L)1.812
Max. Speed (km/h)8
Tire(track) modei8.5-15
Operating load(kg)500
LiftingArc lifting
Bucket capacity(m3)0.25
Rated flux(L/min)40
High Flow Flux(L/min)
Fuel tank capacity(L)50
Self weight bucket(kg)2200
Model
Main technical parameter
JC35
AOverall operating height(mm)3300
BHeight to bucket hinge pin(mm)2725
CHeight to top of cab(mm)2000
DHeight to bottom of level bucket(mm)2558
EOverall length without bucket(mm)2300
FOverall length with bucket(mm)2950
GDumping angle at maximum height(°)40
HDumping height(mm)2050
IDumping reach(mm)790
JRollback of bucket on ground(°)30
KRollback of bucket at full height(°)104
LWheelbase(mm)897
MGround clearance(mm)140
NAngle of departure(°)20
OFront turning radius without bucket(mm)1098
PFront turning radius(mm)1760
QRear turning radius(mm)1296
RRear axle to bumper(mm)964
STread width, centerline to centerline(mm)1080
TWidth(mm)1350
UBucket width(mm)1400
Product Images
0.5t/26kw/0.25m3 Jc35 with CE Skid Steer Loader Images 1
