8 Ton Forklift Truck Factory Seller

  • 8 Ton Forklift Truck Factory Seller
  • USD 1.00 /Unit
  • 1 Unit
  • 27 Unit
  • 27 days
Product Description
8 Ton Forklift Truck Factory Seller China biggest Forklift Truck Supplier with good forklift and competitive price

1. Powerful Engine
Engine for optional: CHAOCHAI6102-BG, ISUZU 6BG1, PERKENS 1104D-TA(EUROIII)
2. Hydraulic Gear-box
3. Control Valve
4. Steering Bridge
5. Double Front Wheel
6. Caution Light

Technical Parameters:
Product Name8 Ton Diesel Forklift Truck
ModelSH80
Load capacity (kg)8000
Load center (mm)600
Power typeDiesel
Max. lifting speeds ( with load ) mm/s350
Max. driving speeds ( with/without load ) km/h26/30
Max. towing ( with/without load ) kn58
Gradeability (with/without load ) %21/20
Lifting height (mm)3000
Free lift (mm)195
Tilting angles ( forward-backward ) (.)6/12
Min. turning radius (mm)3700
Min. right angle aisel width ( mm )3310
Min. under-clearance (mm)250

Dimension
Overall length (including fork)mm5160
Overall width ( mm )2165
Overall height (mast lowered )mm2700
Overall height (mast extend )mm4375
Overall height to overhead guard (mm)2585
Fork overhang (mm)700
Wheel base (mm)2500
TreadFront tread (mm)1600
Rear tread (mm)1700
TyreFront tyre9.00-20-14
Rear tyre9.00-20-14
Total weight (kg)10960
Fork width (mm)170
Fork thickness (mm)70
Backrest height (mm)1374
Fork length (mm)1220


Engine
Engine modelChaochai6102-BG
Rate power (KW)80.9
Rotate speed at Rate power (rpm)2500
Max. torque (nm)353
Rotate speed at max torque (rpm)1650
Battery2-12 V/80AH
Type of power shiftTor-non
Product Images
8 Ton Forklift Truck Factory Seller Images 1
