5 Ton Sh50 Diesel Forklift Truck Seller

  • 5 Ton Sh50 Diesel Forklift Truck Seller
  • USD 1.00 /Unit
  • 1 Unit
  • 69 Unit
  • 9 days
Product Description
5 Ton SH50 Diesel Forklift Truck China SellerWe are chinese biggest forklift trucks seller , with diesel forklift , electric battery forklift truck etc many model forklift trucks , they with good quality and our most competitive price .5 Ton Sh50 Diesel Forklift Truck Seller
Product Name5 Ton Counterbalance Diesel Forklift Truck(F series )
ModelSH50
Load capacity (kg)5000
Load center (mm)500
Power typeDiesel
Max. lifting speeds ( with load ) mm/s350
Max. driving speeds ( with/without load ) km/h22/26
Max. towing ( with/without load ) kn54
Gradeability (with/without load ) %20/27
Lifting height (mm)3000
Free lift (mm)210
Tilting angles ( forward-backward ) (.)6/12
Min. turning radius (mm)3250
Min. right angle aisel width ( mm )3090
Min. under-clearance (mm)230

Dimension
Overall length (including fork)mm4660
Overall width ( mm )1995
Overall height (mast lowered )mm2500
Overall height (mast extend )mm4420
Overall height to overhead guard (mm)2420
Fork overhang (mm)590
Wheel base (mm)2250
TreadFront tread (mm)1470
Rear tread (mm)1700
TyreFront tyre8,25-15-14
Rear tyre8,25-15-14
Total weight (kg)7980
Fork width (mm)150
Fork thickness (mm)55
Backrest height (mm)1365
Fork length (mm)1220


Engine
Engine modelChaochai6102-BG, QC4112G
Rate power (KW)80,9/70
Rotate speed at Rate power (rpm)2500/2300
Max. torque (nm)353/370
Rotate speed at max torque (rpm)1650/1600-1800
Battery2-12 V/80AH
Type of power shiftTor-non
Product Images
5 Ton Sh50 Diesel Forklift Truck Seller Images 1
