3 Ton Electric Forklift Truck with CE Sh30c

  • 3 Ton Electric Forklift Truck with CE Sh30c
  • USD 10000.00 /Unit
  • 1 Unit
  • 23 Unit
  • 21 days
Product Description
3 Ton Electric Forklift Truck with CE Sh30c Forklift Truck Seller with good price

1. High Capacity Battery
2. Comfortable Control
3. High Performance Motor
4. High quality Ge/curtis
Electric Controller
5. Safe Over-guard
6. Caution Light
7. Option AC Electric Control
With CE certificate, good price and best service.
Technical Parameters:
Product Name3Ton DC Counterbalance Electric Forklift Truck
ModelSH30C
Load capacity (kg)3000
Load center (mm)500
Power typeBattery
Max. lifting speeds ( with load ) mm/s290
Max. driving speeds ( with/without load ) km/h14/16
Max. towing ( with/without load ) kn12
Gradeability (with/without load ) %15
Lifting height (mm)3000
Free lift (mm)80
Tilting angles ( forward-backward ) (.)6/12
Min. turning radius (mm)2350
Min. right angle aisel width ( mm )2280
Min. under-clearance (mm) 140

Dimension
Overall length (including fork)mm3705
Overall width ( mm )1240
Overall height (mast lowered )mm2200
Overall height (mast extend )mm4260
Overall height to overhead guard (mm)2200
Fork width (mm)125
Fork thickness (mm)45
Fork length (mm)1070(1220)
Fork overhang (mm)494
Wheel base (mm)1700
TreadFront tread (mm)1000
Rear tread (mm)980
TyreFront tyre28 x 9 - 15
Rear tyre18 x 7 -8
Total weight (kg)4900
MotorTraction motorXQ-10-1C
Lifting motorXQD-13-3S
BatteryBattery type40-DA-500
Battery voltage /Capacity V/Ah80/500
Product Images
3 Ton Electric Forklift Truck with CE Sh30c Images 1
