2.5 Ton Battery Forklift Truck with CE (SH25C)

2.5 ton Battery Forklift Truck with CE SH25C1. High Capacity Battery
2. Comfortable Control
3. High Performance Motor
4. High quality Ge/curtis
Electric Controller
5. Safe Over-guard
6. Caution Light
7. Option AC Electric ControlTechnical Parameters:

Product Name		2.5Ton DC Counterbalance Electric Forklift Truck
Model		SH25C
Load capacity (kg)		2500
Load center (mm)		500
Power type		Battery
Max. lifting speeds ( with load ) mm/s		230
Max. driving speeds ( with/without load ) km/h		12/14
Max. towing ( with/without load ) kn		10
Gradeability (with/without load ) %		15
Lifting height (mm)		3000
Free lift (mm)		60
Tilting angles ( forward-backward ) (.)		6/12
Min. turning radius (mm)		2250
Min. right angle aisel width ( mm )		2100
Min. under-clearance (mm)		110
Dimension	Overall length (including fork)mm	3380
	Overall width ( mm )	1160
	Overall height (mast lowered )mm	2130
	Overall height (mast extend )mm	4040
Overall height to overhead guard (mm)		2130
Fork width (mm)		122
Fork thickness (mm)		40
Fork length (mm)		920(1070)
Fork overhang (mm)		451
Wheel base (mm)		1550
Tread	Front tread (mm)	970
	Rear tread (mm)	950
Tyre	Front tyre	7.00-12
	Rear tyre	18 x 7 -8
Total weight (kg)		4300
Motor	Traction motor	XQ-8
	Lifting motor	XQD-10-3S
Battery	Battery type	D-700
	Battery voltage /Capacity V/Ah	48/700
